Nickel Plate PCB Spot Welding Machine
Nickel Plate PCB Spot Welding Machine for BMS. Automates precise spot welding of nickel strips onto mobile battery protection plates at 3000-5000 pcs/h. Features PLC control, touch-screen interface, and versatile sizing for high-efficiency, consistent quality and easy operation.
- Information
Function Features
1.The capacity of the automatic spot welding machine is about 3000-3500PCS/H.
2.Fully automatic plate feeding device, mobile worktable, spot welding mechanism and PLC programming control system.
3.The length of the nickel piece is set arbitrarily, the automaticfeeding plate is spot welded and sent out, and the effect is good.
4.Computer touch-screen man-machine interface, real-timedisplay of machine running state and function parameters，easy to operate.
Scope of application
It is suitable for spot welding mobile phone battery protection plate straight strip nickel piece, 1 character protection plate nickel spot automatic spot welding.
Technical Parameter
Model：WPM-1500
Supply voltage：AC220V, 50/60Hz
Air Pressure：0.4-0.6MPa
Power：0.8KW
Weight：200KG
Efficiency：3000~5000pcs/h
Display screen：PLC display screen
Width of BMS：20-100mm
Length of BMS：165mm
Machine Dimensions：1075*1060*1420mm
Sample Display
