Lithium core automatic spot welding machine
Lithium Core Automatic Spot Welding Machine. Automates precise spot welding of nickel plates to mobile phone battery cores at 1500-1800pcs/h. Features 0.01mm accuracy, fully automatic feeding, multi-manipulator stability, and user-friendly PLC+HMI for efficient, reliable production with easy monitoring and minimal downtime.
- Information
Function Features
1.The performance of the automatic spot welding machine isabout 1500-1800PCS/H per hour
2.Fully automatic feeding plate, multiple manipulatorsrunning materials in the middle, each working procedureindependently, high efficiency, good stability.
3.The computer touch-screen man-machine interfacedisplays the running state and functional parameters of themachine.
4.The operation interface and clear fault alarm tips enablebeginners to understand and learn easily.
Scope of application
This device is suitable for the spot welding machine connection between the 7 character nickel plate protection plate and the electric core ofthe mobile phone battery.
Technical Parameter
Model：WPM-918
Supply voltage：AC220V 50/60Hz
Air pressure：0.4-0.6MPa
Weight：约 200KG
Machine Dimensions：1480*700*1230mm
Efficiency：1500-1800PCS/H
Moving precision：0.01mm
Control system：PLC+HMI
Noise：<50dB
Power：0.8KW
Maximum size of single plate：W: 60mm, L: 145mm
Maximum size of cell：W: 34mm, L: 165mm (max.)
Programming interface：PLC touchscreen (Chinese)
Welding thickness：0.01~0.15mm
