CCD Welding Spot Quality Inspection Machine
CCD solder joint detection machine is a polymer battery processing automation equipment, with automatic pole ear leveling, front and back solder joint detection, solder joint bad distinction, automatic Discharge and other functions.
- Information
Introduction of use
Features auto tab flattening, welding spot quality inspection of cell front & back sides, poor welding spot identification, and auto discharge functions.
Technological process
Cell feeding & positioning
Tab flattening
Front & back welding spot detection (CCD)
NG auto sorting
OK auto discharge
Technical parameter
Battery dimensions：L:40-120 W:35-90 T:3-10
Tab length：4-20
Tab distance：10-70
CCD identification rate：≥95%
Equipment operating rate：≥99%
Air source pressure：0.5MPa
Total power：2KW
Ambient temp.：0-50℃
Power supply voltage：220V 50Hz
Production capacity：≥1000PCS/H
Machine dimensions LWH (mm)：1200*1200*1900mm
Functional characteristics
Cell feeding & positioning
Tab flattening
With high-resolution image acquisition, high defect recognition rate by AI image processing and recognition technology
Fast identification & high accuracy
Anti-static belt protects batteries
User-friendly intuitive operation
