Universal cylindrical battery five stage sorting machine
Universal Cylindrical Battery Five-Stage Sorting Machine. Automatically sorts 18650/21700/26650+ cells by voltage and IR at 3000pcs/h with ultra-high ±0.025% accuracy, modular design for easy maintenance, and reliable automation for efficient, precise battery grading.
- Information
Function Features
1.18650/21700/26650/26700/32700 universal five level sorting machinefor battery cells, suitable for voltage and internal resistance sorting testson battery cells that have been divided into different capacities inbattery factories.
2.The electrical control part of the sorting system adopts a modulardesign, with high integration, good versatility, and easy maintenance;
3.The executing mechanism adopts stepper motor control, with highaccuracy and good reliability.
4.There are 5 receiving slots in the equipment, and the voltage andintemal resistance values can be set arbitarily. The sorting efficiency ishigh, and the battery can be accurately sent to the specified gearaccording to the set intemal resistance and voltage values.
5.The equipment adopts a material box type feeding method, with thecyinder automatically dividing the material and the personnel manuallyreceiving the material.
6.Truly realizing the automation of battery cell sorting.
Scope of application
Mainly suitable for battery cell models such as18650/21700/26650/26700/32700, suitable for general cell sorting.
Technical Parameter
Model: WPM-500
Host input power supply: Single phase 220V/50Hz
Air Pressure: 0.4~0.6 MPa
Power: 0.5KW
Weight: 180Kg
Efficiency: 3000PCS/H
IR Accuracy: ±0.025%R.D.±6dgt
Voltage Accuracy: ±0.025%R.D.±6dgt
Test mode: 5 channels
Machine dimensions: 1200*550*1400mm
