Cell Bottom Taping Machine
Tail Glue Machine for soft pack battery bottom taping. Automates L/U/C-shape insulation with ±0.25mm accuracy, bubble-free results, ≥1000pcs/h speed, ≥99% yield, and easy model switching for efficient, reliable protection.
- Information
Introduction of use
Designed for insulating tape application on the bottom of batteries, capable of performing three tape patterns: L-shape, U-shape, and C-shape
Technological process
Cell feeding & positioning
Auto tape feeding
Auto taping
Auto tape rolling
Top & bottom tape forming
Left & right tape forming
Auto discharge
Technical Parameter
Battery dimensions：L:40-140 W:35-90 T:3-10
Tape width range：10-20 L/U-shape
Taping accuracy：±0.25
Tape thickness：≥0.03
Equipment operating rate：≥98%
Yield rate：≥99%
Air source pressure：0.5MPa
Total power：1.5KW
Ambient temp.：0-50℃
Power supply voltage：220V 50Hz
Production capacity：≥1000PCS/H
Machine dimensions LWH (mm)：1200*1200*1900mm
Functional characteristics
High compatibility, easy to change cell model, high taping accuracy
Missed-tape detection
Tape rolling system ensures neat taping without bubbles and wrinkles
Forming system ensures left & right tape wrapping
Full-range vacuum monitoring
Anti-static belt protects batteries
User-friendly intuitive operation
