Dual-Side Labeling Machine (FILM LAMINATION)
The double-sided labeling machine is suitable for a variety of labeling and film processing on the front and back of the battery, such as pulling up the label, forming the label, PET film, and other forming double-sided tape.
- Information
Introduction of use
Designed for various labeling and filming on front & back sides of batteries: pull-up labels, pre-formed labels, PET films, and other pre-formed double-sided tape.
Technological process
Battery feeding
Positioning (dual workstations)
Label peeling
Labeling
Label rolling
Discharge
Functional characteristics
Label positioning
Auto alignment system
Label rolling ensures neat labeling without bubbles and wrinkles
Full-range vacuum monitoring
Anti-static belt protects batteries
User-friendly intuitive operation
Technical Parameter
Battery dimensions：L:40-120 W:35-90 T:3-10
Tape core inner diameter：∅76
Tape roll outer diameter：≤350
Labeling accuracy：±0.15
Equipment operating rate：≥98%
Yield rate：≥99%
Production capacity：≥1000PCS/H
Air source pressure：0.5MPa
Total power：3.5KW
Ambient temp.：0-50℃
Power supply voltage：220V 50Hz
Machine dimensions LWH (mm)：1200*1200*1900mm
