Battery pack aging detection cabinet
Battery Pack Aging Detection Cabinet. Enables precise cycle life, capacity, and efficiency testing for lithium-ion batteries. Features high-accuracy measurements (±0.05%), individual channel control, and customizable ranges up to 200V/500A for reliable quality assurance and durability evaluation.
- Information
Function Features
It is primarily used for cycle life testing and quality control in the production or experimentation of materials including lithium-ion, nickel-cadmium, and nickel-metal hydride batteries. Functions include battery cycle life test, battery capacity test, battery charging test, battery discharging test, battery charge retention capability test, battery charge-discharge efficiency test, as well as tests for tolerance to overcharging, over-discharging, and varying rate conditions.
Applicable specification: 60V/20A、60V/40A、60V/80A、60V/160A、75V/20A、75V/40A、75V/80A、75V/160A、100V/15A、100V/30A、100V/60A、100V/120A、150V/10A、150V/20A、150V/40A、150V/80A
Technical Parameter
Communication method: TCP/IP (ports)
Channel control mode: Individual channel control
Charging voltage: 5V-200V
Discharge voltage: 200-2V (Min. voltage customizable)
Recharging current: 0.02A-500A
Discharge current: 0.02A-500A
Voltage accuracy: ± (0.05%RD + 0.05%FS)
Current accuracy: ± (0.05%RD + 0.05%FS)
Sampling frequency: 10ms/per unit
Record time: 100mS-65535S
Main temperature: Optional: 1 temp. test per channel
Voltage resolution: 1mV
Current resolution: 1mA
Temperature resolution: 0.1℃
Input power supply: AC220V±10%/50Hz (Power supply: three-phase five-wire)
Power accuracy: ± (0.05%RD + 0.05%FS)
