Automatic Finished Battery Collector
Automatic Finished Battery Collector. Automates precise grabbing and stacking of finished batteries from conveyor to trays at ≥1000pcs/h. Minimizes manual handling, ensures integrity with anti-static protection, high ≥98% uptime, and optional data scanning for efficient, reliable production.
- Information
Introduction of use
Designed for collecting finished batteries. It can directly pick cells from conveyor belt and accurately stack them in battery trays.
Technological process
Cell feeding & positioning
Width measuring
Defective cell sorting
Length measuring
Thickness measuring
Dual-workstation thickness measuring
Sorting & discharge (scanning & data uploading-optional)
Technical Parameter
Battery dimensions：L:40-120 W:35-90 T:3-8
Battery tray dimensions：L:270-420 W:215-350 T:Stacking height 250
Equipment operating rate：≥98%
Air source pressure：0.5MPa
Total power：2KW
Ambient temp.：0-50℃
Power supply voltage：220V 50Hz
Production capacity：≥1000PCS/H
Machine dimensions L*W*H (mm)：1000*1200*1900mm
Functional characteristics
Auto unloading from conveyor belt to battery tray directly
Reduce manual touching of the battery to ensure its integrity
Full-range vacuum monitoring
Anti-static belt protects batteries
User-friendly intuitive operation
