Electric Core Sub-Cabinet
Electric Core Sub-Cabinet for square lithium battery capacity testing. Enables simultaneous multi-cell evaluation with 5V/3A-640A support, 80% charging efficiency, 75% discharge feedback, and ±0.05% accuracy. Delivers precise, high-throughput results via TCP/IP for efficient battery quality assurance.
- Information
Function Features
This utility model opens up a capacity cabinet for squarelithium battery tests, including: the main body of thecapacity cabinet, which has a cavity for placing multiplebatteries and opening multiple batteries; Multiplepositioningcomponents in the cavity body are used tolocate the battery; multiple fast clamps, the end of theends ofthe telescopic rod is set for fixing boards for fixingpositive heat dissipation probes and negative heatdissipation probes; ltis used to drive positive heatdissipation probes and negative heat dissipation probesat the same time ordownward; and the positive heatdissipation probe and negative heat dissipation probefixed on the fixed board.The positive heat dissipationprobe and the negative heat dissipation probe are incontact with the positive and negative columns ofthebattery,respectively, and the battery test testing thebattery,which significantlyimproves the efficiency ofthecapacity test test.
Applicable specification：5V/3A、5V/6A、5V/10A、5V/30A、5V/40A、5V/60A、5V/80A、5V/120A、5V/160A、5V/240A、5V/320A、5V/480A、5V/640A
Technical Parameter
Communication method：TCP/IP (ports)
Channel control mode：Individual channel control
Energy-saving efficiency of charging：80%
Charging voltage：0~5V
Port discharge voltage：5~1.5V
Charging current：0.02A~3A~640A
Discharge feedback efficiency：75%
Discharge current：0.4A~3A~640A
Voltage accuracy：±(0.05%RD + 0.05%FS)
Current accuracy：±(0.05%RD + 0.05%FS)
