This line handles the entire production process for prismatic cell modules, includes: cell feeding, cell welding, tin welding of BMS circuit board, and final inspection. It supports both coordinated and independent operation, with user-friendly interfaces and separate control systems for each unit. Easy to operate and maintain.
| Item | Indicator | Remark |
|---|---|---|
| Capacity indicator | Efficiency: 6-8PPM | Taking the 280/314Ah cell and 1P13S module as examples. Manual operation time is not included. |
| Total power | ≤150KW | |
| Dimensions(L*W*H) | 37174*12000*3100mm | Actual product may vary due to minor dimensional tolerances or customized structures. |
| Equipment Line Operating Rate | ≥95% | Equipment Operating Rate = (Running Time – Downtime) / Running Time, Downtime caused by non-equipment factors is excluded. |
| Single-machine failure rate | ≤1%, Calculation: failure time /Production line operating time (Note: Based on 30-day cumulative operating time) | Equipment failures lasting ≤10 minutes are not counted. |
| Ambient temperature | -15℃-55℃ | Humidity: 20%-90% |
| Air supply pressure | 0.5 ~ 0.6Mpa | |
| Power voltge | 220V/380V-50Hz/60Hz | |
| Load capacity | ≤500kg/M² | |
| Installation requirement | Flat surface, no vibration or shock |
1. What is an Energy Storage Lithium Battery Pack Line Design Solution?
An Energy Storage Lithium Battery Pack Line Design Solution is a complete production planning and manufacturing solution for lithium battery pack assembly. It covers the design of the production process, equipment selection, layout planning, and automation integration to help customers build efficient battery pack production lines.
2. What production processes are included in this lithium battery pack line?
The lithium battery pack line covers the complete assembly process for prismatic cell modules, including cell feeding, cell positioning, cell welding, BMS circuit board tin welding, and final product inspection.
3. What types of batteries can be produced by this battery pack production line?
This production line is mainly designed for lithium battery packs used in energy storage applications. It can be customized according to different battery cell types, pack structures, capacity requirements, and production processes.
4. Can the lithium battery pack assembly line be customized?
Yes. The production line can be customized based on customers’ requirements, including production capacity, factory space, automation level, battery specifications, and manufacturing processes.
5. What are the advantages of using an automated lithium battery pack line?
An automated lithium battery pack line improves production efficiency, ensures consistent product quality, reduces manual errors, and supports stable large-scale battery manufacturing.
6. How does the production line ensure lithium battery pack quality?
The production line integrates inspection processes to monitor key production steps and ensure battery pack performance, reliability, and safety before delivery.
7. What support can customers get when building a lithium battery pack factory?
Customers can receive one-stop support, including production line planning, equipment configuration, installation guidance, technical training, and after-sales service to help establish lithium battery manufacturing capabilities.
8. What factors should be considered when designing an energy storage battery pack production line?
Important factors include battery specifications, production capacity, automation requirements, factory layout, safety standards, and future expansion plans. A professional design solution helps optimize investment and production efficiency.
9. How long does it take to install and commission the lithium battery pack line?
The installation and commissioning time depends on the production line scale, equipment configuration, and customer requirements. A detailed schedule will be provided after evaluating the project conditions.
10. long does it take to install and commission the lithium battery pack line?
The installation and commissioning time depends on the production line scale, equipment configuration, and customer requirements. A detailed schedule will be provided after evaluating the project conditions.
