BMS Taping & Bending Machine

Protective Plate Glue Bending Machine for battery lateral-side taping. Supports L/U/C-shape insulation with bubble-free, wrinkle-free results at ≥1000pcs/h. Delivers ≥99% yield, easy operation, precise ±0.25mm accuracy, and high compatibility for efficient, reliable polymer battery production.

Information

Introduction of use

Features operations on BMS: applying protective tapes (brown/black/dual-sided tapes), 45° bending, flattening, second 180° bending, auto discharge, etc.

Technological process

Cell feeding & positioning
First bending
Second bending
Forming
Discharge

Technical Parameter

Battery dimensions：L:40-120 W:35-90 T:3-10

Equipment operating rate：≥98%

Yield rate：≥99%

Air source pressure：0.5MPa

Total power：2.5KW

Ambient temp.：0-50℃

Power supply voltage：220V 50Hz

Production capacity：≥1000PCS/H

Machine dimensions LWH (mm)：1200*1200*1900mm

Functional characteristics

Cell feeding & positioning
Tab flattening
With high-resolution image acquisition, high defect recognition rate by AI image processing and recognition technology
Fast identification & high accuracy
Anti-static belt protects batteries
User-friendly intuitive operation
